Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 19/ 56
→ Dead man Door controlled by two keys with
Dead man
behaviour, i.e. the
door only slides as long as the OPENING or CLOSING key is
continuously pressed (24V on signal input).
▪ If the CLOSING and OPENING buttons are pressed at the
same time, the door stops. Both buttons must first be re-
leased before the door can be moved again.
▪ A locked door can only be opened by SSK. The SSK also
has a
Dead man
function. The CLOSING button closes
and locks the door again.
▪ Default parameters:
Parameter Default value
Input/Output → STG →
AUX0_IN
OPENING DEAD MAN
Input/Output → STG →
AUX1_IN
CLOSING DEAD MAN
Input/Output → SIO → Function
SIO
Stop
Input/Output → SIO → Function
SIS
Stop
→ Folding door For standard folding doors (FTA/FBO).
▪ The choice of the right door type is essential in case of
folding doors. Otherwise, the collision recognition might be
wrong.
▪ The A measure (opening width) cannot be learned auto-
matically in case of a folding door. Therefore, to obtain an
ideal motion sequence it has to be configured manually.
Parameter Default value
Door system → A-measure 2000
