Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 18/ 56
→ Breakout USA Door type for the USA
Parameter Default value
Input/Output →
Reset
Disabled
Miscellaneous → Alarm display
→ Collision
Enabled
→ Ratchet Door controlled by a single key for USA applications (garage
door control). With each keystroke (0V -
door changes to one of the following states:
opening
,
closing
or
stopped
.
▪ Door closed: a keystroke opens the door to the open posi-
tion.
▪ Door open: a keystroke closes the door to the closed posi-
tion.
▪ Door is opening: a keystroke stops the door. Another pulse
within 2 seconds closes the door again. A later pulse
opens the door to the open position.
▪ Door is closing: a keystroke reverses the door direction.
The door opens to the open position.
▪ A locked door can only be opened by SSK. The SSK has a
Dead man
-Function at the same time.
▪ In the operating mode
Continuously open
the door opens
automatically.
▪ All safety signals can be used. SÖK/NSK cannot be con-
figured.
Parameter Default value
Input/Output → STG →
AUX0_IN
Ratchet
Input/Output → SIO → Function
SIO
Stop
Input/Output →
Reset
Disabled
