Record system 20 - Page 28

Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 28/ 56
INPUT/OUTPUT → STG
→ BDE_V1
(only STM20/22 DUO)
→ BDE_V2
(only STM20/22 DUO)
(0V) in safety
-
relevant signals (e.g. SIS) means that the
signal has triggered.
▪ Normally, signals for connecting buttons only react to the
signal change over (0V 24V). Thus, for example, the door
can be opened with the AKI button, but will automatically
shut at the end of the hold-open time, even though the but-
ton is still being pressed.
→ Disabled X
→ SÖK/NSK
(only AUX0_IN
and AUX1_IN)
Safety opening or emergency closing.
0V/open = carry out safety opening or emergency closing
24V = back to previous operating mode
▪ Requested function must be configured with Parameter →
Input/Output → SÖK/NSK → Function .
▪ Signal normally has highest priority. An exception is e.g.
active Pharmacy control .
▪ Safety sensors and reverse automatic system are not ac-
tive while closing or opening.
→ SURV Selection of operating mode Locked with clock timer.
0V/open = operating mode Locked
24V = back to previous operating mode
▪ Signal has highest priority, i.e. operating mode Locked
cannot be exited with BDE-D.
▪ SSK and safety sensors are active.
▪ The door closes and locks even in operating modes Manu-
al
and
Continuously open
.
→ BDEM_1
(only AUX1_IN)
Contact S1 of mechanical control unit.
▪ The type of the connected control unit must be configured
according to
Parameter
→
Control unit
→
BDE
-
M
.
→ BDEM_2
(only AUX0_IN)
Contact S2 of mechanical control unit.
▪ The type of the connected control unit must be configured
according to
Pa
rameter
→
Control unit
→
BDE
-
M
.
→ Continuously open Selection of operating mode Continuously open with pulse
button.
▪ 1st pulse (24V -> 0V/open) = operating mode
Continuously
open
2nd pulse (24V -> 0V/open) = back to previous operating
mode
▪ A locked door is unlocked, safety sensors are active while
opening.
