Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 30/ 56
→ Broken rubber cord Monitoring of the rubber cord with door type CO48.
0V/open = rubber cord broken (switch open)
24V = rubber cord fine (switch closed)
▪ In case of torn cord, error 20 is displayed and the door
opens to the full opening width, provided that it is not
locked.
▪ Also, in case of torn cord, all operating modes including
→ Opening dead man Opening button for
Dead man
door type and other button-
operated doors.
0V/open = door stops
24V = door opens
▪ The door opens as long as the button is continuously
pressed. If another button is pressed at the same time, the
→ Closing dead man Closing button for
Dead man
door type and other button-
operated doors.
0V/open = door stops
24V = door opens
▪ The door closes as long as the button is continuously
pressed. If another button is pressed at the same time, the
door stops.
→ AKI button
(not with RED)
Opening to complete opening width with pulse signal (0V/open
-> 24V). The signal is intended for connecting a button on the
inner side of the door.
▪ An automatic door closes at the end of the hold-open time,
even if the button is maintained pressed.
▪ A locked door cannot be opened.
→ Interior button
(only AUX0_IN and
AUX1_IN with RED)
Moving to complete opening width with pulse signal (0V/open -
> 24V).
The signal is intended for connecting a button on the inner side
of the door.
▪ May only be used in an addition to a certified escape route
sensor. The button itself and the opening path over the
button are not monitored.
