Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 34/ 56
→ AKA The output signal indicates that a triggering signal on the outer
side of the door is active.
▪ The output switches independently of the current operating
→ ZLP-1 Additional printed circuit board to connect conventional safety
light barriers. Once identified, a ZLP-ELS (automatic recogni-
tion) can only be reset with the FPC.
→ Without X No additional p.c.b. is connected.
→ ELS Additional p.c.b. for 2 ELS is connected.
→ ZLP-2 (only RED) Additional p.c.b. for RED installations with non-record sensors.
Once identified, a ZLP-AKI (automatic recognition) can only be
reset manually with the FPC.
→ Without X No additional p.c.b. is connected.
→ AKI Additional p.c.b. is connected for AKI on RED installations.
INPUT/OUTPUT → FEM0
→ AUX2_IN
→ AUX3_IN
Configurable input signals on FEM0 (terminals 53 and 57).
▪ For further instructions about every signal, see also
Pa-
→ Disabled X
→ SURV Selection of
Locked
operating mode with clock timer.
0V/open =
Locked
operating mode
24V = back to previous operating mode
→ Continuously open Selection of
Continuously open
operating mode with pulse
button.
1st pulse (24V 0V/open) =
Continuously open
operating mode
2nd pulse (24V 0V/open) = back to previous mode
→ SIS Safety signal in closing direction.
0V/open = security active
24V = security passive
→ SIO Safety signal in opening direction.
0V/open = security active
24V = security passive
→ AKI button reduced
(not with RED)
Opening to reduced opening width with pulse signal (0V/open -
> 24V). The signal is intended for connecting a button on the
inner side of the door.
