Record system 20 - Page 35

Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 35/ 56
→ Interior button reduced
(only with RED)
Opening to reduced opening width with pulse signal (0V/open -
> 24V). The signal is intended for connecting a button on the
inner side of the door.
▪ May only be used in an addition to a certified escape route
sensor. The button itself and the opening path over the
button are not monitored.
→ Broken rubber cord Monitoring of the rubber cord with door type CO48.
0V/open = rubber cord broken (switch open)
24V = rubber cord fine (switch closed)
→ Opening dead man Opening key for Dead man and other button-operated doors.
0V/open = door stops
24V = door opens
→ Closing dead man Closing key for Dead man door type and other button-
operated
doors.
0V/open = door stops
24V = door closes
→ AKI button
(not with RED)
Opening to complete opening width with pulse (0V/open ->
24V). The signal is intended for connecting a button on the
inner side of the door.
→ Interior button
(only with RED)
Opening to complete opening width with pulse (0V/open ->
24V). The signal is intended for connecting a button on the
inner side of the door.
▪ May only be used in an addition to a certified escape route
sensor. The button itself and the opening path over the
button are not monitored.
→ CLOSING button Closing of the door with pulse signal (0V/open -> 24V) for but-
ton-operated door types.
→ Ratchet Pulse signal (0V/open -> 24V) for sequential door control with
door type Ratchet .
→ Emergency opening Triggering of an emergency opening.
0V/open = carry out emergency opening
24V = back to original operating mode
→ SURA Selection of operating mode One-Way with clock timer.
0V/open = operating mode One-Way
24V = back to original mode
