Record system 20 - Page 46

Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 46/ 56
→ Lead time close 1 To warn people of a door closing, it is possible to display it in
advance with the configurable output signal Alarm (see Pa-
rameter → Input/Output ).
0 = no warning, output is passive during closing
1 = no warning, output is active during closing
40 = approx. 8 seconds warning time, output is active during
closing
▪ The door closes after the set lead time. The time starts to
run after the hold-open time has expired.
▪
With
Push to actuate close
there is n
o lead time.
→ Alarm display In this menu, some error messages can be adapted to special
requirements.
▪ Display for AKI/AKA/SSK, or SIO/SIS/ELS.
If the alarm output has been configured, it switches after
expiry of the set time.
→ FlowControl
Red Test limited
This function of the control module is exclusively for record
FlowControl, so that the RED test can be parameterised in the
operating mode „One-way“ to “Automatic“.
→ Disabled X RED test is carried out when changing from „One-way“ mode
to “Automatic“.
→ Enabled RED test is NOT performed when changing from „One-way“
mode to “Automatic“
→ Time activation 18 Triggering signals activated for a relatively long time (AKI,
AKA, SSK) are displayed with an error message.
0 = no error message
1..40 = display an error message after 5..200 seconds
→ Time safety 18 Safety signals activated for a relatively long time (SIO, SIS,
ELS) are displayed with an error message.
0 = no error message
1..40 = display an error message after 5..200 seconds
→ Collision display Display collisions with an error message.
→ Disabled X No error display.
→ Enabled Collisions in opening and closing directions are displayed with
an error message.
