Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 45/ 56
→ Push to actuate open The door will open automatically when it is slid open manually
on approx. 3 mm from the closed position.
▪ This function is not active on a locked door and in operat-
ing mode
One-Way
.
▪ If this function is activated, the holding force in closed posi-
tion is determined by
Parameter → Miscellaneous → Hold-
ing force
.
▪ If a brake is set, it may not be applied in the closed posi-
→ Disabled X Function inactive
→ Normal When opening manually, open up to the width set by control
unit (BDE-D).
→ Partial When opening manually, open up to reduced width.
→ Push to actuate close The door will close automatically when it is slid manually in
closing direction on approx. 30 mm from the open position.
▪ If this function is activated, the holding force in open posi-
tion is determined by
Parameter → Miscellaneous → Hold-
ing force
.
▪ Hold-open time has no influence on this function.
▪ If a brake is set, it may not be applied in the closed posi-
→ Disabled X Function inactive
→ Enabled Close the door by sliding it in closing direction.
→ Holding force 0 Energy required to activate the "Push to actuate" function in
opening and closing direction.
0 = low expenditure of energy
40 = high expenditure of energy
▪ The maximum value (40) corresponds to holding force
without "Push to actuate" component.
→ Lead time open 1 To warn people of a door opening, it is possible to display it in
advance with the configurable output signal
Alarm
(see
Pa-
rameter → Input/Output
).
0 = no warning, output is passive during opening
1 = no warning, output is active during opening
40 = approx. 8 seconds warning time, output is active during
opening
▪ The door opens after the set lead time.
▪ With
Push to actuate open
there is no lead time.
values 0 and 1 can be set.
