SIDE SSD MODULE LEDS
The RED MINI-MAG SIDE SSD and DSMC 1.8" SSD SIDE MODULE have the LED described in the tabled be-
low.
LED COLOR/FLASHING DESCRIPTION
Media Indicator LED Off No media present
Green Ready to record
Red Recording
Red slow flashing Recording; 25% media left
Red fast flashing Recording; 5% media left
Yellow Finalizing
Yellow flashing Accessing media (for example,
when formatting)
