9
The Security Code determines the programming mode and the accessibility
of programming parameters. This code can be used along with the Program
Mode Lock-out (P-Loc) in the User Input Function parameter (Module 1).
Two programming modes are available. Full Programming mode allows all
parameters to be viewed and modified. Quick Programming mode permits only
the Setpoint values to be modified, but allows direct access to these values
without having to enter Full Programming mode.
Programming a Security Code other than 0, requires this code to be entered
at the
CodE prompt in order to access Full Programming mode. Depending on the
code value, Quick Programming may be accessible before the CodE prompt
appears (see chart).
PROGRAMMING SECURITY CODE
000 to 999
USER INPUT
FUNCTION
USER INPUT
STATE
SECURITY
CODE
MODE WHEN “SEL”
BUTTON IS PRESSED
FULL PROGRAMMING
MODE ACCESS
0
Full Programming Immediate Access
not P-Loc
______
1-99
Quick Programming
After Quick Programming
with correct code entry
at
CodE prompt *
100-999
CodE prompt
With correct code entry
at
CodE prompt *
0
Programming Lock No Access
Active
1-99
Quick Programming No Access
P-Loc
100-999
CodE prompt
With correct code entry
at
CodE prompt *
Not Active 0-999
Full Programming Immediate Access
* Entering Code 222 allows access regardless of security code.
6.3 MODULE 3 - DISPLAY AND FRONT PANEL BUTTON
P
ARAMETERS (3-dSP)
SEL
Pro
Front Panel
Display
Select Enable
Display
Update Time
Front Panel
Reset Enable
Programming
Security Code
Zero Display
W/Display
Reset
Display
Color
Units
Indicator
Selection
Backlight Unit Only
3-dSP
dSP-t SEL rSt ZErO UNItS COLOr CodE
Display
Intensity
Level
d-LEVScroL
Display
Scroll
Enable
PARAMETER MENU
The yES selection allows the SEL button to toggle through the enabled
displays.
FRONT PANEL DISPLAY SELECT ENABLE (SEL)
This selection allows the RST button to reset the selected value(s).
FRONT PANEL RESET ENABLE (RST)
The yES selection allows the display to automatically scroll through the
enabled displays. The scroll rate is every 4 seconds. This parameter only appears
when the MAX or MIN displays are enabled.
DISPLAY SCROLL ENABLE
NOyES
dSPNO
HI
LO
HI-LO
NOyES
This parameter activates the Units Indicator on the display. There are two
methods of selecting the Indicator. List will present a group of Units
preprogrammed into the meter. Segments allows the user to choose which of the
segments should light.
UNITS INDICATOR SELECTION
LISt SEGSOFF
Enter the desired display color, red or green. This parameter is active for
backlight units only.
DISPLAY COLOR (BACKLIGHT UNIT ONLY)
6rnrEd
Enter the desired Display Intensity Level (1-5). The display will actively dim
or brighten as levels are changed. This parameter is active for backlight units only.
DISPLAY INTENSITY LEVEL (BACKLIGHT UNIT ONLY)
1 to 5
1
dSP-t
yES
SEL
dSP
rSt
NO
ScroL
This parameter enables the RST button or user input to zero the input display
value, causing the display reading to be offset.
Note: For this parameter to operate, the
RST button or User Input being used
must be set to dSP and the Input value must be displayed. If these conditions are
not met, the display will not zero.
ZERO DISPLAY WITH DISPLAY RESET
NOyES
NO
ZErO
OFF
UNItS
rEd
COLOr
5
d-LEV
000
CodE
DISPLAY UPDATE TIME
This parameter sets the display update time in seconds.
1
0.5
2
seconds
To Next Page
