6.8 mOdUle 8 - analOg OUTpUT parameTers () Ñ
PARAMETER MENU
Enter the analog output type. For 0-20 mA or 4-20 mA
use terminals 18 and 19. For 0-10 V use terminals 16 and
17. Only one range can be used at a time.
ANALOG TYPE
ANALOG ASSIGNMENT
SELECTION
0 to 10 V
4 to 20 mA
0 to 20 mA
RANGE
Enter the Display Value that corresponds to 0 mA (0-20
mA) , 4 mA (4-20 mA) or 0 VDC (0-10 VDC).
ANALOG LOW SCALE VALUE
ANALOG HIGH SCALE VALUE
ANALOG UPDATE TIME
PROBE BURN-OUT ACTION (PAXT ONLY)
to
to
to
Enter the source for the analog output to retransmit:
= Display Input Value
= Maximum Display Input Value
= Minimum Display Input Value
= Totalize Display Value
Enter the Display Value that corresponds to 20 mA (0-20
mA) , 20 mA (4-20 mA) or 10 VDC (0-10 VDC).
Enter the analog output update rate in seconds. A value
of 0.0 allows the meter to update the analog output at a
rate of 20/sec.
Enter the probe burn-out action. In the event of a
temperature probe failure, the analog output can be
programmed for low or high scale.
Ñ - An analog output card must be installed in order to access this
module.
