Red Sea MAX E Series User Manual

Red Sea MAX
®
E-Series
114
6 背滤组件的安装
MAX
®
E-系列水族箱分成两部分，水族箱和背滤。背滤储藏所有过滤和循环系统。
1. 可拆卸表面除油膜水流刷
2. 蛋白质分离器
3. 滤材架
4. 活性碳
5. 循环泵
6. 水泵出水口喷嘴
7. 滤棉
8. 过滤缸超流盘
9. 水流架/插栓
10. 配件组
11. 回流泵出水口（用于升级）
12. 加热棒（不提供）
13. 制冷机泵（不提供）
E-170
背滤组件装配图标识了可供选择的加热棒、制冷机和管件的位置。
10
11
13
9
7
2
5
6
3
1
8
4
12

Red Sea MAX E Series Specifications

General

Model	MAX E-170, MAX E-260
Skimmer	Included
Available Colors	Black, White
Integrated Power Center	Yes
Heater	Not included
Total System Volume	170 liters (45 gal), 260 liters (69 gal)
Display Tank Volume	Varies by model
Rear Sump Volume	Varies by model
Lighting	LED
Lighting Control	WiFi controlled ReefBeat app
Return Pump	2150 lph / 570 gph (MAX E-170), 2150 lph / 570 gph (MAX E-260)
Cabinet	Marine-Spec cabinet
Glass Thickness	12 mm (1/2")
Protein Skimmer	Included
Dimensions	57.5 cm x 57.5 cm x 142 cm / 22.6" x 22.6" x 56" (MAX E-170), 90 cm x 57.5 cm x 142 cm / 35.4" x 22.6" x 56" (MAX E-260)
