14
6.3 Media Rack:
The media rack is supplied
pre-assembled and placed in its
normal operating position within
the media compartment of the
rear sump. Familiarize yourself
with the media rack by removing
and reinserting it to the media
compartment.
6.4 Carbon:
Wash the carbon filter material
under running water several
times to remove residual dust. It
is recommended to soak it in water for 24-72 hrs. before usage otherwise
during the first 3 days after set-up the carbon may float and release
micro air bubbles from inside its pores.
Place the washed carbon onto the designated shelves on the media rack.
Ensure that the bag does not protrude outside the frame of the rack.
6.5 Flow Grills:
The circulation pump chambers are prepared
for flow grills to be added when the system
is upgraded to the in-cabinet sump. For the
surface skimmer to operate effectively in the
standard rear sump configuration the flow
grills are closed. These will be replaced with
open grills when the upgrade is performed.
6.6 Sump Screen:
Position the sump screen above the front wall of the rear sump. Align the
hinges above the clips on the top of the side walls and push firmly into
position. Push the rear of the sump screen until it clicks into position.
To rotate, pull the top of the screen forward until the screen lays flat on
the top of the tank.
6.7 Circulation Pumps:
Familiarize yourself with the
multidirectional outlet as shown in the
drawing.
Familiarize yourself with the circulation
pump by disassembling and reassembling
all of the component parts. Ensure that
the impeller chamber cover is correctly
positioned and properly secured by the
bayonet ring and that the flow valve is in
the fully open position. Screw the hose
barb provided into the outlet of the pump.
1. Before use, check that the pump and
power cable are not damaged.
Media Rack
