Red Technology MAGIC-2 - Tool Changing Procedure; Exchanging Engraving Tools

17
CHANGING TOOL
Using 2.5 T-Wrench that comes with the machine, take out the tool loosing tool fastening bolt and fasten it after
new tool is inserted.
Tool length is not so important, but 10~20mm is recommended.
◈ EXCHANGING TOOL
☞ When the bolt is loosed, take care not to drop the tool. To prevent this, hold the tool with your finger while
loosing the bolt.
10~20mm
