Redarc BCDC1240-LV - Product Specifications

CONTENTS
Table of Contents Page
Warnings and Safety Instructions 01
Contents 02
Specifi cations 02
1 Product Function 03
1. Alternator Input 03
2. Solar Input 03
3. Charging Algorithm 04
4. Turn On/Off Thresholds 04
5. External LED Indication 05
6. Display Panel 05
7. Error Codes 06
2 Installation 06
1. Wiring 08
3 Troubleshooting 12
4 Frequently Asked Questions 11
5 Two Year Warranty 14
Specifi cations
BCDC1240-LV
DC Input Voltage Range 9V-32V
Gel/AGM Std Lead Acid Calcium Content
Absorption Voltage 14.5V 14.9V 15.3V
Float Voltage 13.3V 13.3V 13.3V
No Load Current <100mA
Standby Current <8mA
Input Fuse Rating 12V/24V 50A/30A (Not supplied)
Output Fuse Rating 50A (Not supplied)
Output Power 600W
Ambient Temperature -20°C to +80°C
Minimum O/P Battery Volts 4.2V
Weight 680g
Dimensions 150x120x37mm
Warranty 2 years
Standards CE, C-Tick, AS/NZS CISPR11:2004
2
