3 OPERATION
3.8 LED Indication
The Tow-Pro
™
Elite will indicate both Mode and Fault Condition through colour and flash
sequences of the LED indicator. The table below shows how the Tow-Pro
™
Elite will
indicate Normal Operation of the unit.
NOTE: LEDs will glow full brightness when gain control is adjusted or manual
override is pressed. After release of the gain control knob the LED brightness
will reduce. This is designed to be less intrusive on driver’s vision at night.
Status Indication
Mode Proportional User Controlled
Calibration Blue/Green flashing Not Applicable
Sleep Mode
1
Blue Breathing on button push
2
Trailer Connected Solid Blue Solid Green
Braking Blue to Red
3
Green to Red
3
1. Sleep Mode occurs when there is no trailer connected to the vehicle.
2. Breathing, as opposed to flashing, is the LED gradually getting brighter until its brightest point and then gradually
dimming until off.
3. The LED will vary between the Mode Colour (Blue or Green) and Red depending on the braking force.
