1 SPECIFICA
TIONS
Kit Contents
1
.
Remote
Head Assembly
2
.
Main Unit
3
.
Remote Head Nut
4
.
Remote Head Knob
5
.
Remote Head Bezel
6
.
RJ45 Remote Head Cable (1m)
7
.
Main Unit
Wires & Connector (0.5m)
Dimensions & Connection
4
1
2
4
3
5
6
7
10.0mm
10.0mm
Brake
Lights
(RED)
Input
Power
(BLACK)
Ground/
Earth
(WHITE)
Brake
Output
(BLUE)
Remote Head
Connection
23.7mm
19.0mm
(Recommended)
11.5mm
20.0mm
20.0mm
43.5mm
46.5mm
4
6
Table of Contents
1 Specifications
4
Table of Contents
4
2 Installation
6
Mounting the Main Unit
6
Wiring the Brake Controller
7
Red Wire (Vehicle Brake Light) Connection
7
Wiring Diagrams
8
Mounting the Remote Head
9
Active Calibration
10
3 Operation
11
Adjusting the Braking Force
11
Manual Override
11
Operating Modes
12
Proportional Mode (Blue LED)
12
User Controller Mode (Green LED)
12
Changing Modes
13
Park Brake Feature
13
Electric / Hydraulic Brakes
14
24V Vehicle Systems
14
Visual User Guide
15
LED Indication
16
Troubleshooting
17
4 Periodic Maintenance/Checks
20
5 Frequently Asked Questions
21
6 Notes
22
7 Two Year Product Warranty
23
