Redarc LFP1225 User Manual

9
2 INSTALLATION
12V
Fuse*
All ground points must
be connected to chassis
earth.
Auxiliary
Battery
Start
Battery
Fuse*
Note: Power wires must be
at least 6mm² and must be
crimped using an
appropriate crimp tool.
INPUT
Not Used
(Leave Disconnected)
*Fuse Ratings as per table on Page 2
LFP1225 & LFP1240
Loads
Load
Fuse
Low Voltage
Disconnect
Red
Blue
Orange
Black
Brown
Green
12V
Fuse*
All ground points must
be connected to chassis
earth.
Auxiliary
Battery
Start
Battery
Fuse*
Note: Power wires must be
at least 6mm² and must be
crimped using an
appropriate crimp tool.
INPUT
Not Used
(Leave Disconnected)
to vehicle
ignition
*Fuse Ratings as per table on Page 2
Loads
Load
Fuse
Low Voltage
Disconnect
Red
Blue
Orange
Black
Brown
LFP1225-LV & LFP1240-LV
Green
Figure 2.8b - LFP1225-LV and LFP1240-LV Standard
setup for a 12V Start Battery
Figure 2.8a - LFP1225 and LFP1240 Standard setup for
a 12V Start Battery
