Redarc LFP1225 User Manual

10
2 INSTALLATION
All ground points must
be connected to chassis
earth.
Not Used
(Leave Disconnected)
SOLAR
Loads
Fuse*
12V Solar Panel
Array
Load
Fuse
Note: Power wires must be
at least 6mm² and must be
crimped using an
appropriate crimp tool.
Auxiliary
Battery
INPUT
*Fuse Ratings as per table on Page 2
Low Voltage
Disconnect
Red
Blue
Orange
Black
Brown
Green
ALL MODELS
Figure 2.8c - Standard setup for a 12V Solar array
24V
Fuse*
All ground points must
be connected to chassis
earth.
Auxiliary
Battery
Fuse*
Note: Power wires must be
at least 6mm² and must be
crimped using an
appropriate crimp tool.
INPUT
Not Used
(Leave Disconnected)
*Fuse Ratings as per table on Page 2
LFP1225 & LFP1240
Loads
Load
Fuse
Low Voltage
Disconnect
Red
Blue
Orange
Black
Brown
Green
Start
Battery
Figure 2.8d - LFP1225 and LFP1240 Standard setup for
a 24V Start Battery
