Redring EXPRESSIONS REVIVE User Manual

19
Please Note:- The fitting of Spare Parts must be supervised by a suitably qualified person.
Front Cover Revive Cat No. 93672174 Thermal Cut-Out Cat No. 93672109
Front Cover Revive-Plus Cat No. 93672175 Pressure Switch Assembly Cat No. 93672124
Heat Exchanger (7.2kW) Cat No. 93672122 Terminal Block Set Cat No. 93672128
Heat Exchanger (8.5kW) Cat No. 93672102 End Cap c/w Metal Clip Cat No. 93672178
Heat Exchanger (9.5kW) Cat No. 93672103 Elbow c/w Metal Clip Cat No. 93672179
Heat Exchanger Vessel Cat No. 93672183 Metal Clip Set Cat No. 93672180
Solenoid Valve Cat No. 93672176 6-Mode Handset Cat No. 93672159
Start / Stop Switch Cat No. 93590713 Chrome Shower Hose Cat No. 93672119
Flow Valve Top Assembly Cat No. 93672105 Ø25mm Hose Retainer Cat No. 93672163
Tank Clip Cat No. 93672106 Ø25mm Height Adjuster Cat No. 93672161
Pressure Relief Device Cat No. 93672107 Ø25mm Riser Rail Tube Cat No. 93672158
Heat Exchanger ‘O’-Rings Cat No. 93672108 Ø25mm Riser Rail Brackets Cat No. 93672160
Detachable Lower Section Cat No. 93672177 Ø25mm Clear Soap-Dish Cat No. 93672162
Phased Shut-Down Relay Cat No. 93597878 Phased Shut-Down PCB Cat No. 93550835
Expressions Revive Showers
Expressions Revive-Plus Showers
COMMON SPARE PARTS
CIRCUIT DIAGRAMS
