Redring POWERSTREAM RPS95 User Manual

SPARE PART DETAILS
1a
93 79 37 07
Neon & Clip 9.5kW
2
93 79 37 89
Thermal Cut-Out 2-Disc 57/90°C
3
93 79 37 03
Terminal Block 3 way
4
93 79 37 09
Cable Clamp & Rubber Boot
5
300002259
Backplate
6
93 79 38 18
Flow Switch Assy
7a
93 79 38 19
Heat Exchanger Assy (9.5kW 240V)
7b
93 79 38 20
Heat Exchanger Assy 10.8kW 240V)
7c
93 79 38 21
Heat Exchanger Assy (12kW 240V)
Pg. 13
300002291
Front Cover & Trims
Pg. 13
300002293
Front Cover Fixing Screws
Dia. 6
93 79 37 57
Gate Valve
APPLICABLE MODELS
Cat No: 078931 RPS95 Powerstream Heater 9.5kW 240V IPX4
Cat No: 078421 RPS108 Powerstream Heater 10.8kW 240V IPX4
Cat No: 078438 RPS12 Powerstream Heater 12kW 240V IPX4
Item.No
Cat.No.
Description
12
