HOW TO INSTALL YOUR
POWERSTREAM
THIS APPLIANCE MUST BE INSTALLED, INNITIALLY COMMISSIONED AND
SERVICED BY A QUALIFIED PERSON IN ACCORDANCE WITH THE NATIONAL
AND LOCAL REGULATIONS IN FORCE IN THE COUNTRY OF INSTALLATION.
DO NOT INSTALL WHERE IT MAY BE SUBJECTED TO FREEZING CONDITIONS.
Diagram 2a Diagram 2b
The Powerstream is recommended to supply a MAXIMUM of two washbasins (see diagram 2a)
OR a washbasin and shower (see diagram 5b).
If the Powerstream is connected to a mixer tap, then only NON-Thermostatic types should be
used (water mixes at the outlet pipe only).
The Powerstream is NOT to be fitted to a bath or kitchen sink other than for hand-washing
purposes. (See product flow rate tables on page 3).
BEFORE YOU START
For mains electrical connection and associated information please refer to page 7 of this booklet.
Check the pressure of the main water supply, 1 bar – 6 bar. The appliance must not be directly
connected to a water supply greater than 6bar. If mains pressure is greater than 6 bar please refer to
page 5.
To operate correctly, the unit requires the following - 1-6bar and 3-4L/min.
FIXING THE UNIT TO THE WALL
Deciding the position
• If being used in a public place, position the unit out of reach to discourage vandalism.
• Fit the unit onto a flat piece of wall, well away from any potential splashes of water or spray.
• Position the unit either upright or lengthways (diagram 2a/b), whichever is most convenient for
plumbing and wiring, keeping the hot water pipe length to a minimum (less than 3m is
recommended) and insulate the pipe in order to save energy.
• If the unit is to supply a basin, you can fit it either above or below the basin.
