ASSEMBLY
Step 1
Attach the Front Stabilizer (2) to the Main Frame (1),tighten x 2 Carriage Bolt (31),
Curve Washer (16) and Domed Nut (17).Then, attach the Rear Stabilizer (3) to the
Main Frame (1), tighten x 2 Carriage Bolt (15), Curve Washer (16) and Domed Nut
(17).
Step 2
Take the Front Post (4) and join the Computer Wire (21) with the lower computer
wire (35).Attach the Front Post with Frame (1) and tighten with x 3 Hex Bolt (18)
and Curve Washer (19). Connect the Computer Wire (21) with Upper Computer
Wire (23). Then Slide the Computer (6) onto the computer holder of Front Post (4)
and tighten with Screw (34).
