Part Name QTY Par t Name QTY
51 Disc cover 2 76 R sticker 1
52 Allen indented nut M10xP1.5 2 77 Front stabilizer 1
53 hex screw M8*20 10 78 Iron core 2
54 Flat washer 25*8.5*2.0t 4 79 Front stabilizer cover 2
55 Left foot plate 1 80 Stabilizer end cap 4
56 Right foot plate 1 81 Front stabilizer wheel 2
57 pedal(L&R) 1 set 82 Stabilizer adjustment screw 4
58 Bearing 2203-2RS 2 83 Rear stabilizer 1
59 C type ring 4 84 Computer 1
60 Left foot plate tube rear cover - lower 1 85 Water bottle 1
61 Left foot plate tube rear cover - upper 1 86 Water bottle holder 1
62 Right foot plate tube rear cover - lower 1 87 Power adaptor 1
63 Right foot plate tube rear cover - upper 1 88 Controller 1
64 Plastic insert 10 89 Screw M8 x 50 4
65 Foot plate tube front cover - left 2 90 Arc washer 20x9x2.0t 14
66 Foot plate tube front cover - right 2 91 Foot plate knob 4
67 Action arm left 1 92 Hex screw M10*65 2
68 Action arm right 1 93 Philips screw M5X10 4
69 Bearing 6200ZZ 4 94 Screwdriver 1
70 Wave washer Ø31.8xØ20x0.3t 2 95 Spanner 1
71 Action arm cover inner 2 96 Allen Key 6MM 1
72 Action arm cover outer 2 97 Allen key5MM 1
73 Action arm foam tube Ø35x3.0tx725 2 98 Lubricant 1
74 Action arm end cap Ø35*1.5t 2 99 Controller FBZAC-10 1
75 L sticker 1 100 Cross head screw 2
TX2.0 PARTS LIST
Part Name QTY Par t Name QTY
1 Frame 1 26 Belt 4.8X300 4
2 Bearing 6003ZZ 6 27 Sensor fixed base 1
3 Plastic belt pulley Ø310 1 28 Speed sensor 1
4 Crank Shaft 1 29 Round head self tapping screw ST4.0x16 1
5 Flat head hex screw M6x16 4 30 Left Chain cover 1
6 Nylon nut M6 4 31 Right Chain cover 1
7 Magnet ( With Plastic base) Ø15x7t 1 32 Upright lower cover 1
8 C-Clip with Ø17 axle 2 33 Upright cover insert 1
9 Bushing 1 34 Button Ø8*72.5 4
10 Wave Washer 1 35 Self tapping screw M4X16 49
11 Flywheel 1 36 Upright 1
12 Column head hex screw M6*70 2 37 Foam tube with Ø31.8 Column,Length 203mm 2
13 Washer 15x7x2.0t 2 38 Foam tube with Ø31.8 Column,Length 147mm 2
14 Spring washer M6x1.5t 2 39 Pulse sensor 2
15 Flywheel fixing plate 2 40 Pulse sensor wires 1
16 Bearing 6000ZZ 3 41 Handlebar end cap 2
17 C-Clip with Ø17 axle 1 42 Middle Control wire 1
18 Counter sunk philips screw 3 43 Guide Thread 1
19 Power Supply wire 3 44 Upright upper cover front 1
20 Foam Grip NCD301870-H 1 45 Upright upper cover rear 1
21 Lower control wire 1 46 Upright Post Sleeve 2
22 Belt 510J6 1 47 Handlebar axle 1
23 Motor 1 48 Cross Brace 2
24 Round head philps self tapping screw 4 49 Foam 38mm x 38mm x 2.0t 4
25 Regulating screw 1 50 Disc 2
