TX1.0 PARTS LIST
Part Name QTY Par t Name QTY
51 Disc cover 2 76 R sticker 1
52 Allen Indented Nut M10xP1.5 2 77 Front stabilizer 1
53 Hex ScrewM8*20 10 78 Iron core 2
54 Washer 25*8.5*2.0t 4 79 Front stabilizer cover 2
55 Left foot plate 1 80 Stabilizer end cap 4
56 Right foot plate 1 81 Front stabilizer wheel 2
57 Foot plate 1 set 82 Stabilizer adjustment screw 4
58 Bearing 2203-2RS 2 83 Rear stabilizer 1
59 C shape circlip Ø40 4 84 Computer 1
60 Left foot plate tube rear cover - lower 1 85 Water bottle 1
61 Left foot plate tube rear cover - upper 1 86 Water bottle holder 1
62 Right foot plate tube rear cover - lower 1 87 Power adaptor 1
63 Right foot plate tube rear cover - upper 1 88 None 0
64 Plastic insert 10 89 Hex Screw M8x50 4
65 Foot plate tube front cover - left 2 90 Washer 20x9x2.0t 14
66 Foot plate tube from cover - right 2 91 Foot plate knob 4
67 Action arm left 1 92 Hex Screw M10*65 2
68 Action arm right 1 93 Cross head screw M5X10 4
69 Bearing 6200ZZ 4 94 Phillips screwdriver 1
70 Washer Ø31.8xØ20x0.3t 2 95 Spanner 1
71 Action arm cover - inner 2 96 Allen key 6 mm 1
72 Action arm cover - outer 2 97 Allen key 6 mm 1
73 Action arm foam tube Ø35x3.0tx725 2 98 Lubricant 1
74 Action arm end cap 2 99 Cross head screw M4xP0.7x16 1
75 L sticker 1 100 Cross head screw M5xP0.8x16 1
Part Name QTY Par t Name QTY
1 Frame 1 26 Belt 4.8x300 4
2 Bearing 6003ZZ 6 27 Sensor Fixed Base 1
3 Plastic Belt PlateØ310 1 28 Speed sensor 1
4 Crank Shaft 1 29 Round head self tapping screw ST4.0 x16 1
5 Flat Head Hex Screw M6x16 (10.9 grade) 4 30 Left chain cover 1
6 M6 Nylon Nut 4 31 Right chain cover 1
7 Magnet W/Plastic BaseØ15x7t 1 32 Upright Lower Cover 1
8 C-Clip(17 shaft) 2 33 Upright Cover Insert 1
9 Busing 1 34 Snap Ø 8 * 72.5 4
10 Washer 22x 17.5x0.3t 1 35 Philips Screw M4X16 45
11 Flywheel 1 36 Upright 1
12 Washer Ø18XØ10X2.0t 2 37
Foam tube withØ31.8Round tube used length203mm
2
13 Allen Nut 3/8"x26 2 38
Foam tube withØ31.8Round tube used length147mm
2
14 Adjustment Screw 2 39 Pulse sensor 2
15 Nut M6 2 40 Pulse sensor wires 1
16 Idler wheel PBJ4024,6000z Bearing 1 41 Handlebar End cap 2
17 Bushing 1 42 Middle control wire length1400mm 1
18 Nylon Nut 3 43 Belt length 1000mm 1
19 Power suppl ywire 950mm 1 44 Upright upper cover front 1
20 Induction wire 950mm 1 45 Upright upper cover rear 1
21 Lower control wire 570mm 1 46 Sleeve 2
22 Belt 510J6 1 47 Handlebar Axle 1
23 Motor 1 48 Cross Brace 2
24 Round Head Philips Tapping Screw 4 49 Shockproof foam 38 mm x 38mm x 2. 0 t 4
25 Resistance Cable 1 50 Disc 2
