10
Battery Replacement
When the low battery symbol appears on the LCD, the batteries
must be replaced.
1. Turn the meter off and remove the test leads.
2. Carefully remove the tilt stand located in the rear of the meter.
3. Remove the 4x Phillips head screws holding the battery cover.
4. Remove the battery cover.
5. Replace the 6x AA batteries.
6. Properly secure the cover and tighten the screws.
7. Reattach the tilt stand.
Applications
• Power Tools
• Appliances
• Motors
• Cables
Application Notes
Power Tools & Small Appliances
This test applies to any device being tested that uses a line cord. For
double insulated power tools, connect one lead to the device's housing
(i.e. chuck, blade, etc.) and the other lead to the end of the power cord.
AC Motors Testing
Disconnect the motor from the line by disconnecting the wires from the
motor terminals or opening the mains switch. If the main switch is used
and the motor also has a starter then the starter must be held, by some
means, in the "ON" position. In the latter case, the measured resistance
will include the resistance of the motor, wire and all other components
between the motor and the main switch. If a weakness is in indicated, the
motor and other components should be checked individually. If the motor
is disconnected at the motor terminals, connect one lead to the grounded
motor housing and the other lead to one of the motor leads.
continued...
REED Instruments
1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com
