7
Operating Instructions
Connecting the Test Leads
Connect the red test lead to the VΩ Input Jack and the black test lead to
the COM Input Jack.
Checking Test Leads
1. Set the rotary switch to the 200Ω range.
2. Touch both test lead tips together.
3. Resistance should read less than 00.5Ω and audible tone
should sound.
4. The display should read innity as indicated by "1" when the tips are
not in contact or are not connected to the meter.
Note: Readings other than those described indicate faulty test leads.
The test leads will need to be replaced prior to using the meter. Failure
to follow these instructions could result in damage to the equipment
and electrical shock.
Insulation Resistance Measurements
Warning: Do not perform any Insulation Resistance measurements if
there is AC Voltage present on the device being tested.
1. Connect the test leads to the meter (see Connecting the Test Leads
section for details).
2. Set the rotary switch to the required MΩ test voltage.
3. Connect the tips of the test leads to the equipment being tested.
Note: If voltage is present, the meter will emit a constant beeping sound
while displaying the voltage.
4. The LCD display will show "1"until a test is performed.
5. Press and hold the TEST button to begin.
Note: Do not release the TEST button until testing is complete and make
sure not to turn the rotary switch while the test button is pressed, or the
meter will be damaged.
continued...
