9
Low Resistance (Continuity) Measurements
1. Set the rotary switch to the 200Ω •))) Position.
2. Connect the test leads to the meter (see Connecting the Test Leads
section for details).
3. Connect the tips of the test leads to both ends of the circuit
under test.
4. Read the resistance in Ω on the LCD.
5. When the resistance on a circuit is below approximately 40Ω, the
meter will emit a continuous beep.
AC/DC Voltage Measurement
1. Connect the test leads the meter (see Connecting the Test Leads
section for details).
2. Set the Rotary switch to the ACV or DCV position.
3. Connect the test leads IN PARALLEL to the circuit being measured.
4. Note the measured value.
Auto Power Off
To preserve battery life, the meter is programmed to turn off after 15
minutes of inactivity. To turn the meter back on, turn the rotary switch to
OFF, then back to the desired function.
Data Hold
1. While taking a measurement, press the HOLD button to freeze the
current readings on the display.
2. While in this mode a "HOLD" symbol will appear on the LCD.
3. Press the button again to resume normal operation.
Backlight
Press the button to turn the LCD display backlight on. The backlight
will automatically turn off after approx. 15 seconds.
REED Instruments
1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com
