Specifications
Voltage
Ranges: 250V, 500V, 1000V
Accuracy: DC: ±(0.8% rdg. + 3 dgt.)
AC: ±(1.2% rdg. + 10 dgt.)
Resolution: 1V
OHMS
Ranges: 200Ω, 200kΩ
Accuracy: ±(1.0% rdg. + 2 dgt.)
Resolution: 0.1Ω, 0.1kΩ
Meg OHMS
Ranges: 200MΩ/250V, 2000MΩ/500V,
0 to 1000MΩ/1000V, 1000 to 2000MΩ/1000V
Accuracy: ±(3.0% rdg. + 5 dgt.)
Test Current: 250KΩ, 500KΩ, 1MΩ
Resolution: 0.1MΩ, 1MΩ, 1mA
General Specifications
Range Selection: Autoranging/Manual
Display: LCD with dual display
Display Hold: Yes
Sampling Rate: 2.5 times/seconds
Backlit Display: Yes
Continuity Check: Audible signal if resistance ≤40Ω
Kick Stand: Yes
Auto Power Off: Yes (after 15 minutes)
Power Supply: 6 AAA Batteries
Low Battery Indicator: Yes
Fuse Protection: Yes
Replaceable Test Leads: Yes
Overange Indicator: Yes
continued...
