Reed Instruments R8080 User Manual

11
AC/DC Signal Output Jack
ThemeterisequippedwithanAC/DCoutputjacktoconnectandinte-
gratewithexternalsystems.Forexample,theACoutputcanbeusedwith
a frequency analyzer or oscilloscope to identify the frequency level during
a measurement. The DC output is used to identify the dB level during a
measurement.
AC/DC Output Connector 3.5mm Sub-Miniature Phone Jack
Connector Diagram
AC Output Voltage Range 1VrmsatFS(fullscale)
(FSreferstotheupperlimitoftheselected
dBlevelrange.Forexampleif30-90dBis
theselectedlevelrange,1Vrms=90dB)
DC Output Voltage Range 10mV / dB
Applications
• PreventativeMaintenance
• IndustrialMachinery/Equipment
• ConstructionSites
• EnsuringSafeWorkingConditions
• PublicVenues/Concerts
• CodeEnforcement
• Trafc
• ApplianceNoiseTesting
• Long-termMeasurement
• RecordingofAcousticLevelsforEnvironmentalImpactStudies
REED Instruments
1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com
