In the following, we will describe the programmable functions in the sequence in which they are called up on the
remote control by pressing the mode button.
Several submenus (functions or servo selection) are available within a programmable function. Switch these by pressing
the "Select" button (ill. 3, pos.7).
Please read the entire chapter carefully before programming your remote control!
For precise information please have a look in the operating instructions of your remote control.
Attention!
All settings, mixers and functions are only performed correctly if the adjustment elements (servos, gyros,
etc.) are plugged into the receiver in a certain sequence.
Slot Receiver Function/adjustment element
CH 1 Swash plate right servo front
CH 2 Swash plate servo rear
CH 3 Rotation speed Rotation speed adjuster
CH 4 Gyro Gyro (plug with 3 cables)
CH 5 Gyro sensitivity Gyro (plug with 1 cable)
CH 6 Swash plate Left front servo
Selecting the memory
Select a model memory in this function.
Data reset (RESET)
This function allows the model memory to be reset to the factory settings.
Setting the modulation type
Attention! In the setting "PCM", the remote control only works with the receiver installed in your helicopter.
PPM modulation means "Pulse position modulation". Changing the modulation type to PPM allows you to
operate any 40 MHz FM PPM receiver and the matching channel of the receiver crystal with your transmitter.
Setting the model name
With this function, you can enter a separate name for each model memory. Max. 4 alphanumerical characters are
available per memory slot.
