OSSD (MODULE MOSAIC M1S, MI8O4, MO4L)
The OSSD (static semiconductor safety outputs) are short circuit protected.
They supply:
• In the ON condition: Uv-0,75V...Uv (where Uv is 24V ± 20%)
• In the OFF condition: 0V...2V r.m.s.
The maximum load of 400mA@24V corresponds to a minimum resistive
load of 60. The maximum capacitive load is 0.82F. The maximum
inductive load is 2mH.
Different output configurations (configurable with MSD configuration
software) can be set:
• 4 single channels (1 Safety Output per channel with its relative
feedback input).
• 2 dual channels (2 Safety Outputs per channel with their relative
feedback input).
• 1 dual channel and 2 single channels.
OSSD (MO4LHCS8)
MO4LHCS8 provides 4 High Current Safety Outputs single channel (2A max
per channel).
These outputs are short circuit protected, cross circuit monitored and supply:
• In the ON condition: (Uv-0,6V)...Uv (24VDC ± 20%)
• In the OFF condition: 0V...2V r.m.s.
The maximum load of 2A@24V corresponds to a minimum resistive load of
12. The maximum capacitive load is 0.82F. The maximum inductive load
is 2.4 mH.
Different output configurations (configurable with MSD configuration
software) can be set:
• 4 single channels (1 Safety Output per channel with its relative
feedback input).
• 2 dual channels (2 Safety Outputs per channel with their relative
feedback input).
• 1 dual channel and 2 single channels.
Using MO4LHCS8 with sum output current > 5 A, then separate adjacent
modules by interposing a MSC connector.
