reflex
Underhäll
Reflex ex-avskiljare —
Svenska — 11
Anslutning
Anslutning
Typ:
82531 xx
82532 xx
82533 xx
82534 xx
Typ:
82521 xx
82522 xx
82523 xx
82524 xx
DN 50/65
OD 60.3/76.1
400 mm
300 mm
DN 80/100
OD 88.9/114.3
550 mm
400 mm
DN 125/150
OD 139.7/168.3
750 mm
500 mm
DN 200
OD 219.1
1000 mm
700 mm
DN 250
OD 273.0
1350 mm
850 mm
DN 300
OD 323.9
1700 mm
1000 mm
B: Minimalt utrymmesbehov under avtappningskranen
Typ:
82511 xx 82513
xx
Typ:
82531 xx
82532 xx
82533 xx
82534 xx
50 mm
50 mm
