Reflex Exvoid A 60.3 User Manual

reflex
Vedlikehold
Reflex ex-fraskiller — Norsk — 11
Tilkobling
Tilkobling
Type:
82531 xx
82532 xx
82533 xx
82534 xx
Type:
82521 xx
82522 xx
82523 xx
82524 xx
DN 50/ 65
OD 60,3 / 76,1
400 mm
300 mm
DN 80 / 100
OD 88,9 / 114,3
550 mm
400 mm
DN 125 / 150
OD 139,7 / 168,3
750 mm
500 mm
DN 200
OD 219,1
1000 mm
700 mm
DN 250
OD 273,0
1350 mm
850 mm
DN 300
OD 323,9
1700 mm
1000 mm
B: Minimum plassbehov under tappekranen
A: Minimum plassbehov over
lufteoverdelen
Type: 82511 xx
82513 xx
Type:
82531 xx
82532 xx
82533 xx
82534 xx
50 mm
50 mm
