Reftek REF TEK 130-GPS User Manual

Rev H REF TEK 130-GPS Users Guide 5/20/2021
96259-00-UG
2 Reftek Systems Inc.
System Overview
The REF TEK 130-GPS clock which is shown below, is capable of providing both time and position
information, serially, for host systems in the REF TEK 130 Series Data Acquisition System family.
Each 130-GPS is a self-contained unit. The unit is designed around the receiver module. The
receiver board is based on either the Garmin™ unit. The antenna is mounted on the inside top
of the case and the whole unit is situated so that the antenna has clear overhead exposure. A
single interface connector is located at one end of the case. The 130-GPS can be powered by 12
VDC from the host system and supplies the time and position information serially to the host
system together with a 1 Hertz pulse.

Reftek REF TEK 130-GPS Specifications

General

Brand	Reftek
Model	REF TEK 130-GPS
Category	Measuring Instruments
Language	English
