Reftek REF TEK 130-GPS - RT552 GPS Interface Board; RT552 GPS Interface Board Primary Functions

Rev H REF TEK 130-GPS Users Guide 5/20/2021
96259-00-UG
Reftek Systems Inc. 5
Below are examples of recommended taping when done with 2 layers.
A 2 layer complete tape job on the integrated Hockey-Puck version.
NOTE: For ground level installation move the connector to the side location before application of the tape.
Ground
placement
connector
location
130-GPS
