REFUsol 20K-2T (853P020.200)
User manual
Qualified Person
When inverter is working, it contains lethal voltages and went hot in some area.
Improper installation or maloperation could cause serial damage and injury. To
reduce the risk of personal injury and to ensure the safe installation and operation
of the product, only a qualified electrician is allowed to execute transportation,
installation, commissioning, and maintenance. REFU Elektronik GmbH does not
take any responsibility for the property destruction and personal injury because of
any incorrect use.
Label and Symbols
REFUSOL 20K-2T (853P020.200) has type label attach the side of product which
contact important information and technical data, the type label must permanent
attached to the product.
REFUSOL 20K-2T (853P020.200) has warming symbol attached the product which
contact information of safety operation. The warming symbol must permanent
attached to the product.
Installation location requirement
Please install the inverter according to the following section. Place inverter in an
appropriate bearing capacity object (such as solid brick wall, or strength equivalent
mounting surface, etc.) and make sure inverter vertical placed. A proper
installation location must have enough space for fire engine access for
maintenance if faulty occur. Ensure the inverter is installed in a wall ventilated
environment and have enough air-cooling cycle. Air humidity should less than 90%.
