To change the pre-amp gain.
The Cursa 3 amplifier output level or gain can be set to three
different levels; this is performed by putting the amplifier in to a
programming mode on turning on the amplifier.
Please note the amplifier is set to normal output (level 2) in the
factory, this setting being suitable for most normal Hi-fi
requirements.
Settings -
Pre-amp output level (with rated input levels)
Level 1 = 212mV @ 100 Ohms
Level 2 = 830mV @ 100 Ohms
Level 3 = 1.25V @ 100 Ohms
Maximum output level 8.8V
Pre-amplifier gain levels to pre-amplifier output.
Gain range or level 1 gain = 0dB (unity gain)
Gain range or level 2 gain = 11.5dB (factory setting)
Gain range or level 3 gain = 15dB
Any adjustments made to the power amp link switch and gain must
be carried out by an authorised Rega dealer.
If work is carried out by any person other than a Rega dealer it will
invalidate your warranty.
