14
Specifications
Input sensitivity for rated output levels
Note - Factory setting of gain range level 2
CD, tuner, Line 1, line 2, Tape input sensitivity = 220mV Load, 10K Ohm
Phono input sensitivity (Moving Magnet) = 2.3mV Load 47K in parallel with 100pF
Phono input sensitivity (Moving Coil) = 175uV Load 100 Ohms in parallel with 4700pF
Pre-amp output level (with rated input levels)
Level 1 = 212mV @ 100 Ohms
Level 2 = 830mV @ 100 Ohms
Level 3 = 1.25V @ 100 Ohms
Maximum output level 8.8V
Pre-amp out 1&2 are connected in parallel.
The pre-amp output is DC coupled with full DC protection.
Volume control LED display & step data
Each step of the volume control = 1dB
Each LED represents = 4dB
Total control range = 80dB (20 LED's @ 4dB/LED)
Tape output (with rated input levels)
215mV @ 560 Ohms
Power consumption
7 Watts @ 230/115V
Remote Control
Phillips RC5 system number 16 (audio pre-amp)
Recommended operating temperature
10 - 35°C
Cursa 3 manual.qxd 10/12/2002 15:23 Page 15
