10
SPECIFICATIONS
AMPLIFIER OUTPUT
Power Amplier Output (at rated 230/115V supply voltage) 105W per channel into 8Ω
127W per channel into 6Ω
162W per channel into 4Ω
Note: Continued high level use into loads of 6Ω or less may cause
the case to exceed 40°C above ambient temperature and activate
the thermal shut down.
Headphone Output No Load 11.5V
300Ω 8.1V
54Ω 3.6V
32Ω 2.4V
Source Impedance 109Ω
DISTORTION
THD+Noise (at 1dB below clip into 8Ω measurement bandwidth 22Hz to 22kHz)
Direct Input (Power Amplier) Typically 0.005% at 1kHz
Line Inputs Typically 0.007% at 1kHz
Preamplier Output Typically 0.004% at 1kHz
FREQUENCY RESPONSE
Bandwidth (at 80W into 8Ω)
Direct Input 12Hz (0.5dB) to 95kHz (-3dB)
Line Inputs 10Hz (-1dB) to 85kHz (-3dB)
Phono Input 15Hz (-3dB) to 85kHz (-3dB)
RIAA Accuracy Better than ±0.5dB 100Hz to 20kHz
SENSITIVITY
Input Sensitivity (for 105W into 8Ω)
Line Inputs 2-5 and Record 196mV load 10k
Phono 2mV load 47k in parallel with 220pF
Direct Input 760mV load 50k
Power Amplier Gain 31.6dB
Output Sensitivity (at rated inputs)
Record Output 196mV
Pre-amplier output 760mV
DIGITAL INPUTS
Input D1 S/PDIF Isolated 0.5V 75Ω Co-axial
Input D2 S/PDIF Optical Toslink
Supported Sampling Rates 32, 44.1, 48, 88.2, 96, 176.4, 192kHz
Supported Bit Depths 16 to 24 bit
THD+Noise (DAC Output from Tape Out) Typically 0.004% at 1kHz
DIMENSIONS AND WEIGHT
Dimensions (WxHxD) 432 x 82 x 340mm (17 x 3.25 x 13.4in)
Net Weight 12.5kg (27.5lbs)
Packed Weight 14kg (30.9lbs)
POWER
Power Supply AC supply 230V / 220V / 115V / 100V nominal ±10%
Power Consumption 375W at 1dB below clip into 8Ω
Fuse Ratings T8 AL 250V - 230V 50Hz / 220V 60Hz
T4 AL 250V - 115V 60Hz / 100V 50/60Hz
Remote Batteries AAA (1.5V) x 2
