18 STR 0PA
Status indication by means of LED diodes:
LED ERROR (red) – blinks red in case of failure eventually lights in the parameter setting mode
LED OPEN / MENU (green) – in the ON/OFF mode it lights with a control action for the opening
direction eventually blinks with accessing the MENU mode
LED CLOSE / PAR (red) – in the ON/OFF mode it lights with a control action for the closing direction
eventually blinks besides the chosen parameter in the menu and lights up at writing the parameter into
the memory
- LED I1 / SEL (yellow) – permanent lights with active input I1, or flash in the mode of parameters set
up.
- LED I2 (yellow) – permanent lights with active input I2
- LED POWER (green) – it light on at leading the power supply
Electronics - programme selections option
- relay R1; R2: : disabled; open position, close position, torque-open, torque – close, torque open or
torque close, torque open or position open, torque close or position close, open, close, movement,
movement flasher, to position, from position, warning, remote control, local control (not valid for this
type of the EA), control shut off.
- relay READY: errors, errors or warnings, errors or no remote, errors or warnings or no remote.
- output signál (from EPV passive): 4 to 20 mA; 20 to 4 mA.
- control programme options (regulating): 2P, 3P, 3P/2P I2
- input control signal (N): 0/4/12 up to 20 mA, 4 up to 12 mA, resp. 0/2 up to 10 V.
- input I1: DISABLED, ESD, DBL (local releasing - not valid for this type of the EA), STOP
- input I2: DISABLED, ESD, DBL (local releasing - not valid for this type of the EA), 2P (with active
controller - to enable program control 3P/2P I2 - enables control by binary inputs 24V DC with active
input I2).
- FAILURE REACTION: OPEN, CLOSE, STOP, SAFE POSITION
The identical functions cannot be set on I1 & I2 inputs in addition to the OFF state (e.g., if the ESD)
function is set on I1 input, it is not possible to select the ESD function on I2 input at the same time.
