Regada Rematic - Procedure for Setting Individual Parameters and the Register of Errors and Warnings

STR 0PA 21
3.2 Procedure for setting individual parameters and the register of errors and
warnings
- is given in the separate attachment 74 1053 02 of these operating instructions.
The factory default setting of individual programmes shown in Table 2, as long as otherwise specified by the
customer:
Table 2
Factory default settings of individual parameters in version without local control; possibility to set-up
by operating the control unite buttons.
For the individual parameters set-up see appendix 74 1053 02
MENU NAME FACTORY SETTING-UP
1 TORQUE 100% of value shown on nameplate for OPEN & CLOSE direction.
2 END POSITION
- C = Position + O = Position - end position switching closed and
open from position if valve type is not specified
- C = Torque + O = Position - closed in end by thrust position
and end position switching open from position for single-seat
valves
- C = Torque + O = Torque – switching in both end positions by
thrust for double-seat valves
3 TORQUE BLOCKING
- 2 sec. blocking time
- 5% blocking position for OPEN & CLOSE direction
4 READY RELAY
- errors (READY COM-NO relay contacts closed in error free
conditions)
5 RELAY 1...5
- position O for relay relay R1
- position C for relay R2
- from position 95% for relay R 1
- from position 5% for relay R 2
6 CPT (output signal) 4 to 20 mA
REGULATION – (according to
specification)
2P 3P
7
ANALOG INPUT - 4 to 20 mA (2 up to 10 V)
8 DEAD ZONE - 3 %
9 FAILURE REACTION STOP
Other parameters set-up is possible to change only by using the PC software
TITLE FACTORY SETTING-UP
THERMOSTAT TEMPERATURE 25 °(space heater OFF temperature)
INTERNAL DEAD ZONE 2 % (only for 3P)
SAFE POSITION 0 %
FUNCTION I1
ESD
ACTIVE I1
high level
FUNCTION I2
disabled
ACTIVE I2
high level
THERMAL FUSE FAILURE
functionless with this EA type
THERMAL FUSE RESET
functionless with this EA type
CYCLE MODE disabled
CYCLE RUNNING TIME 10 s
CYCLE PAUSE 50 s
CYCLE POSITION O1 0 %
CYCLE POSITION O2 100 %
CYCLE POSITION C1 0 %
CYCLE POSITION C2 100 %
O AND C TOLERANCE 1 %
CREATE BACKUP
START
RESTORE FROM BACKUP
START
RESTORE FACTORY SETUP
START
ACTIVE ERRORS
CLEAR
