STR 0PA 5
• with effect of salient water from all directions - (product in enclosure IP x4)............................AD 4*
• a possibility of partial or complete immersion - (products with protection enclosure IP x7) .....AD 7*
• with mild dustiness - with possibility of nonflammable effect, nonconducting and explosion-proof
dust; medium layer of dust; descent of dust more than 35 but not more than 350 mg/m
2
per day
(product in enclosure IP 5x).....................................................................................................AE 5*
• with strong dustiness – with a possibility of influences of inflammable, non-conducted and non-
explosive dust; the middle layer of dust; the dust drop more than 350 but not more than 1000
mg/m
2
per day (products with protection enclosure of IP 6x)...................................................AE 6*
• with atmospheric appearance of corrosive and spoiling materials (with high degree of corrosive
aggressiveness of the atmosphere; the presence of the corrosive spoiling materials is significant ..
...............................................................................................................................................AF 2*
• with a possibility of influences of mechanical stress:.
• of mean sinusoid vibrations with frequency in range 10 to 150 Hz, with amplitude of shift
0,075 mm for f<f
p
and with amplitude of acceleration 9,8 m/s
2
for f>f
p
; (contact frequency f
p
is
57 to 62 Hz).......................................................................................................................AH 2*
• of mean sinusoid vibrations with frequency in range 10 to 150 Hz, with amplitude of shift
0,15 mm for f<f
p
and with amplitude of acceleration 19,6 m/s
2
for f>f
p
; (contact frequency f
p
is
57 to 62 Hz) – applies for 4 pillars version ...................................................................AH 2*
• medium impacts, shakings and vibrations........................................................................ AG 2*
• growing of plants and moulds .................................................................................................AK 2*
• with strong danger of presence of animals (insects, birds, small animals) ..............................AL 2*
• with harmful effects of radiation:
• of escaping stray current ..............................................................................................AM 2-2*
with intensity of magnetic field (direct and alternating of power supply frequency) to 400 A.m
-1
• mean sunshine with intensity > 500 a ≤ 700 W/m
2
............................................................AN 2*
• mean seismic effects with acceleration > 300 Gal ≤ 600 Gal .................................................AP 3*
• with indirect danger of storm activity ..................................................................................... AQ 2*
• with fast moving of air and strong winds ......................................................................AR 3 , AS 3*
• with frequent contact of the staff with earth potential (persons often touch conductive parts or they
stand on the conductive basement) ....................................................................................... BC 3*
• without occurrence of dangerous media in the object .............................................................BE 1*
* Marking in accordance with IEC 60364-1, IEC 60 364-5-51 and IEC 60 364-5-55 within valid edition
1.7.3 Power Supply and Operation Modes
Power supply:
Electric motor............................................................110/120 V AC, 220/230/240 V AC, resp.24 V AC ±10%
Control.................................................................................................................binary inputs 24 V DC ±10%
..input control signal 0/4/12 up to 20 mA, 4 up to 12 mA resp. 20 up to 0/4/12 mA, 12 up to 4 mA,
or 0/2 up to 10 V, or 10 up to 0/2 V
Frequency of power supply .................................................................................................... 50/60* Hz ±2%
* At frequency of 60Hz the operating speed is 1,2 times reduced.
Duty cycle - according to IEC 60034-1, 8:
EA STR 0PA are designed - for remote control:
• short-time operation S2-10 min
• intermitted operation S4-25%, 6 up to 90 cycles per hour
- for automotive regulation:
• intermitted operation S4-25%, 90 up to 1200 cycles per hour.
Note:
The operation modes consist of the loading type, load factor and connection/switching frequency.
