32 SP 1, SP 2, SP 2.3, SP 2.4
SPR1, SPR 2, SPR 2.3, SPR 2.4
Z521a..............connection of SPR 1 with controller and resistant feedback for electric motor 24 V AC
Z521b..............connection of SPR 2 – SPR 2.4 with controller and resistant feedback for electric motor 24 V AC
Z522a..............connection of SPR 1 with controller and current feedback for electric motor 24 V AC
Z522b..............connection of SPR 2 – SPR 2.4 with controller and current feedback for electric motor 24 V AC
Z409................wiring diagram of SPR 1 up to SPR 2.4 with controller and resistant feedback for electric motor
3x400 V AC, without reverse contactor
B1 ......... single resistant transmitter
B2.......... double resistant transmitter
B3.......... capacitive transmitter, or el. position
transmitter
C............ capacitor
E1.......... space heater
F1.......... electric motor thermal protection
F2.......... space heater thermal switch
I/U.......... input (output) current (voltage) signals
M........... electric motor
H1.......... indication of “open” limit position
H2.......... indication of “closed” limit position
H3.......... indication of “electric local control”
M........... electric motor
N............ position controller
R............ resistor
SA1........ rotary switch with key
“remote-0-electric local” control
SA2........ rotary switch “open-stop-closing”
S1.......... torque switch "open"
S11 ....... double torque switch "open"
S2.......... torque switch "closed"
S22 ....... double switch "closed"
S3.......... position switch "open"
S4.......... position switch "closed"
S5.......... additional position switch "open"
S6.......... additional position switch "closed"
KM1, KM2.....reverse contactor
R
L
........... voltage-dropping resistor
X............ terminal board
XC......... connector
Y............ brake of electric motor
Notes:
1. In case, that output signal from the capacitive transmitter (wiring diagram Z241a) is not used (incomplete
circuit between terminal 81 and 82), it is required to connect terminals 81 and 82 by jumper (jumper is connected
at manufacturing plant for connecting to terminal board only). By using output current signal from capacitive
transmitter it is needed to remove jumper.
2. For the EA version with feeding voltage 24 V AC is not needed to connect ground wire PE.
3. In the version equipped with the controller device while using the feedback from transducer CPT; when using
the output signal there has been no galvanic isolation of the signal from the input one!
4. In case that galvanically separated output signal is needed it is necessary to use galvanical separation
element (is not part of delivery), e.g. NMLSG.U07/B (producer SAMO Automation s.r.o.). After discussion this
module could be supplied by EA producer.
