1.6.2 Operation Environment
According to valid standard IEC 60 721-2-1, there are delivered these versions of electric
actuators:
1) Version „temperate“ for type climate temperate
2) Version „tropical“ for type climate tropical and dry
3) Version „marine“ for type climate marine.
In accordance with IEC 60 364-1, IEC 60 364-5-51 and IEC 60 364-5-55 within valid edition the EA
have to resist external effects and operate reliably:
In the conditions of the following types of environment:
• mild to hot dry with temperature in range -25°C to +55°C ......................................................AA7*
• with relative humidity 10 to 100 %, including the condensation of up to 0,029 kg water content per
1 kg of dry air at 27 °C, with temperatures from -25°C up to +55°C..........................................AB7*
• with height above sea level 2 000 m, with barometric pressure range 86 to 108 kPa ..............AC1*
• with splash water effects from all directions (protection enclosure IP x4).................................AD4*
• with shallow immersion – (product shielding IP x 7) ..................................................................AD7*
• with moderate dustiness - with effects of flame-proof, non-conducting and explosion-proof dust,
medium cover of dust; dust fall more than 35 but at most 350 mg/sq. m per day (protection
enclosure IP 5x).......................................................................................................................AE5*
• with effects of flame-proof, non-conducting and explosion-proof dust, medium cover of dust; dust
fall more than 350 but at most 1000 mg/sq m per day (protection enclosure IP 6x)..................AE6*
• with atmospheric occurrence of corrosive and pollution media.................................................AF2*
• with possibility of effects of: medium sinusoid vibrations with frequency in range from 10 up to 150
Hz, with shift amplitude of 0.075 mm for f<f
p
and with acceleration amplitude of 9,8 m/s
2
for f>f
P
(transition frequency f
P
is from 57 up to 62 Hz) (applies to 2 pillars version).............................AH2*
• with possibility of effects of: medium sinusoid vibrations with frequency in range from 10 up to 150
Hz, with shift amplitude of 0.15 mm for f<f
p
and with acceleration amplitude of 19.6 m/s
2
for f>f
P
(transition frequency f
P
is from 57 up to 62 Hz) (applies to 4 pillars version).............................AH2*
• medium impacts, shocks and vibrations ................................................................................. AG2*
• with serious danger of plants and mould growing.....................................................................AK2*
• with serious danger of animal occurrence (insects, birds, small animals).................................AL2*
• with damaging effects of radiation:
• erratic current leakage, with intensity of magnetic field (DC and AC, line frequency) to 400 A/m
............................................................................................................................................AM2-2*
• with effects of medium seismic activity with acceleration > 300 Gal < 600 Gal........................AP3*
• with indirect endanger by storm.............................................................................................. AQ2*
• with quick air movement and strong wind........................................................................AR3, AS3*
• without occurrence of dangerous media in the object...............................................................BE1*
• with persons frequent touching earth potential (persons often touch conductive parts or they stand
on the conductive basement) ................................................................................................ BC 3*
*Marking in accordance with IEC 60364-1, IEC 60 364-5-51 and IEC 60 364-5-55 within valid edition
