Engine & Controls
1-65
A hydraulic power assist steering system is optional equipment. e
hydraulic pump used in the system is shown below and provides
“power” for the system. e system consists of two circuits; a
hand operated manual system being the control element, and the
hydraulic pump which is the working element.
e manual system consists of a helm pump with internal check
valve design with integrated relief, and a built-in reservoir. Two
separate steering lines along with a compensating which provide
a complete route for the uid, and a steering cylinder to move the
steering device on the boat from port to starboard.
e power system, is a hydraulic type pump with electronic controls
STEERING-HYDRAULIC POWER ASSIST
