Systems
The status LED’s denote the type of charge being distrib-
uted to the batteries.
1. The FAST CHARGE indicates the battery charger is
sending a higher output which reaches deeper into the bat-
tery plates. This cycle stops once the battery reaches 14.8
volts. This sets the stage for the next charging cycle.
2. The ABSORPTION CYCLE is calculated by the charger
software for an optimum recovery and time frame. Indi-
vidual adjustable settings then are used to provide a safe
and perfect charging cycle for individual batteries.
3. The FLOAT CYCLE maintains the battery at the best
battery voltage.
Note: If a continuous load should discharge a battery the
charger output returns to the high current FAST CHARGE
cycle.
The battery charger starboard face provides a set of fault
LED’s.
1. OVER VOLTAGE
2. UNDER VOLTAGE
3. CHARGER OVER TEMPERATURE
4. BATTERY OVER TEMPERATURE
For further information on the battery charger refer to the
vendors manual in the owner’s packet.
PREVENT SEVERE INJURY OR DEATH
DUE TO HIGH VOLTAGE!
FLIP THE THE TRANSFORMER BREAKER
TO THE “OFF POSITION” BEFORE
ATTEMPTING TO REPAIR OR REPLACE
THE BATTERY CHARGER.
