Regency P121 - P121 LC-2 (Left Corner) Main Assembly Parts

Regency
®
P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace 43
181
100
10
2
98
99
173
146
173
17
138
158
24
11
206
206
151
150
226
224
224
149
151
204
34
35
9
32
BRICK PAN E LS
146
141
204
171
171
1
225
225
PARTS LIST
P121LC-2 (LEFT CORNER) MAIN ASSEMBLY
1) 360-528 Door Assy Front - Tempered
360-538 Door Assy Front - Ceramic
(Optional)
2) 360-529 Door Assy Side - Tempered
360-539 Door Assy Side - Ceramic
(Optional)
9) 360-046 Nailing Strip - Top - Front
10) 360-047 Nailing Strip - Top - Side
11) 430-001 Standoff - Top
17) 360-086 Gasket - Relief Door
24) * Relief Door Assembly
32) 362-528 Brick Panel Base (Set of 6)
34) 902-603 Brick Panel - Side Std. Red
35) 902-604 Brick Panel - Front Std. Red
98) 910-366 Switch Cover Plate
99) 910-363 Wall Switch
100) 910-367 Switch Receptacle Plastic Box
910-882 Wire - Valve to Burner Switch
138) 360-069 Heat Shield - Front
141) 360-031 Column Finishing Trim
146) 360-035 Finishing Trim
149) 360-122 Magnet Bracket - Corner
150) 360-123 Magnet Bracket - Front
151) 904-258 Magnet
158) 360-062 Door Cover Assembly-Front
171) 360-920 Louver Front - Black (set)
360-922 Louver Front - Black/Gold (set)
360-924 Louver Front - Black/Steel (set)
173) 360-932 Louver Side - Black (set)
360-934 Louver Side - Black/Gold (set)
360-936 Louver Side - Black/Steel (set)
204) 360-940 Dec. Grill Front - Black (set)
206) 910-171 Fan Axial 115V
224) 360-942 Dec. Grill Side - Black (set)
225) 948-216 Regency
®
Logo Plate
226) 910-142 Thermodisc
918-519 Manual
*Not available as a replacement part.
Part # Description Part # Description Part # Description
