Reliance 520 - Model 520 Chair Assembly

5
7, 8
6
42
MODEL AND SERIAL
3
1
NUMBER PLATE
19.09"
30.94"
44.00" LOW
46.50" HIGH
BASE TRAVEL
8.75" LOW
11.25" HIGH
11.12"
38.96"
40°
BASE
21.00" LOW
23.50 HIGH
BASE TRAVEL
8.75" LOW
11.25 HIGH
28.88" LOW
31.38" HIGH
BASE TRAVEL
8.75" LOW
11.25 HIGH
7.55"
FIGURE 5
520 CHAIR ASSEMBLY
IN-520
15
ITEM PART NO. DESCRIPTION ITEM
PART NO. DESCRIPTION
1
Chair Top Assembly* (See Figure 6)
2
Chair Base Assembly* (See Figure 7)
3
Headrest Assembly* (See Figure 9)
4
2342203 Footrest
5
3070973
Upholstered Seat Assembly W/Hole**
3070673
Upholstered Seat Assembly W/O Hole**
7
2347373 Upholstered Armrest Assembly - RH**
8
2347473 Upholstered Armrest Assembly - LH**
6 3070573 Upholstered Apron Assembly**
** Please specify upholstery color when ordering.
To order complete Upholstery Set use P/N.
3085673 Upholstery Set - 520 & 522 with holes
3070873 Upholstery Set - 520 & 522 without holes
