Reliance 520 - Page 19

ITEM
PART NO.
DESCRIPTION ITEM
PART NO. DESCRIPTION
1
2081203 Base
16
0458999 Tubing-5-1/2 in
2
2065599 Base Cover
17
1081999 Tubing Insert
3
2065199 Base Housing - Low - RH
18
0559999 Thrust Bearing
2065399 Base Housing - High - RH
19
0560099 Thrust Washer
4
2065299 Base Housing - Low - LH
20
0123885 Lock Nut
2065499 Base Housing - High - LH
21
1127599 Union Tee
5
Lift Assembly (See Figure 8)
22
1659299 Power Cord Assembly
6
1707792 Solenoid Valve Assembly-120V 23 1550599 Chair Control Cable-LV To LV
1707892 Solenoid Valve Assembly-230V 24 2346492 Footswitch Assembly
7
1702892 Keyshield Assembly-Low*
25
1634299 Fuse, 6.3 A / 250V-120V
1702992 Keyshield Assembly-High* 1634999 Fuse, 4 A / 250V-230V
8
2720092 Pump/Motor Assembly-120V
26
1976799 Power Entry Module W/ Filter
2720192 Pump/Motor Assembly-230V
27
Fusedrawer, 2 Pole (In Item 26)
9
1547899 Piston Rod Bolt 28 0458999 Tubing-5 in
10
1525899 Set Screw-#10-24 x 1/4
29
1597299 Capacitor, Starting-120V
11
0607299 Washer 2002199 Capacitor, Starting-230V
12
2721092 Hose Assembly
30
1720399 PH Phil w/Lock Washer-#10-24 x 1/2
13
1596292 Pressure Tube Assembly
31
2081099 Housing Mount Bracket
14
2025599 P.C. Board Assembly
32
0708599 HHCS 3/8-16 x 1.5
15
2720892 AC Input Assembly
33
1569999 Circuit Board Support
To order complete Base Assembly use P/N’s.
2724092 Chair Base Assembly - Low - 120V*
2724192 Chair Base Assembly - High - 120V*
2724292 Chair Base Assembly - Low - 220-240V*
2724392 Chair Base Assembly - High - 220-240V*
*Please specify paint color when ordering.
IN-520
19
